무소음공기압축기, Air Compressor, LAC-61XY
자동 수분제거장치 장착
특징
u Super Silent Air Dryer System
With Air Dyer, Cooling System and Metal Moveable Silent Cabinet.
Air compressor, can be with air dryer system & silent cabinet.
Low working noise, create a quiet working environment.
u Low vibration.
With special rubber feet, reduce vibration during operation.
u Pure air flow.
Oil free design, no lubrication oil needed during operation.
u Core technology.
Diamond hardness cylinder ensure durable working performance.
u Fashion and durable design.
Compact structure, light weight. Under normal situation, can be used
for more than 20000hours.
u Use safety.
With multiple self protection system, if here will be abnormal with pressure,
current or voltage, the motor would cut off automatically to ensure equipment
and personal safety.
u Easy operation.
Quite simple operation, connect to power supply, then no need any more
maintenance, just drainage regularly.
u Low energy consumption.
Full automatic design, automatic stop and restart control, low consumption.
u High precision filtration.
With double filters, ensure high precision of outlet air flow.
u Tank inside has done anti-rust treatment.
Ensure pure outlet air flow for medical equipments.
u Full Automatic Water Drain System
Full automatic water drain, cooling air dryer and air tank
규격
Model |
LAC-61XY |
Pump |
Oil less Double Head Pump |
Air Dryer |
Air dryer with cooling system |
Flow Rate |
118 L/min at 0 bar |
Power |
600 W |
Volt / Hz |
110 ~ 220V / 50~60 Hz |
Pressure |
5~8 bar |
Tank Capacity |
24 L |
N.W |
56.8 kg |
Dimension |
620 x 500 x 900 mm |
Noise Level |
42 dB |
Speed |
1750 rpm |
Restart Pressure |
5 Bar |
Max Pressure |
8 Bar |
Water Drain for Air Dryer |
Automatic drain |
Water Drain for Tank |
Manual Drain |
