웰플레이트 항온 진탕 배양기, Well Plate Thermo Shaking Incubator, ST60-4
ST70-2 Micro-Plate shaker incubator adopts micro processing techniques combined with PID control. Small size, low noise, elegant appearance,
simple operation. Mainly used in micro plates, cell culture plate solution which is mixed or incubated at proper temperature
특징
1、LCD display, set and actual temperature display simultaneously, time and shaking speed.
2、User friendly touch operation interface, the streamlined fuselage, beautiful appearance, convenient cleaning.
3、Two-side heating of micro plates that allows achieving exact correspondence of the set and actual temperature in
wells of the micro plates.
4、The microprocessor controls the time and temperature, good linearity, temperature oscillation speed accuracy,
small fluctuation.
5、Can configure 4 standard microtiter plates and plates, alarm signal after operation ends.
6、Power restore function, equipment can restore to operate as the original set automatically.
7、DC brushless motor drive, long service life, free of maintenance.
규격
Model |
ST70-2 |
ST60-4 |
Speed Range |
300 ~1200rpm |
300 ~1200rpm |
Shaking Orbit |
3mm (horizontal) |
2mm (horizontal) |
Temp. Control Range |
R.T.+5℃ ~70℃ |
R.T.+5℃ ~70℃ |
Temp. Setting Range |
5℃ ~70℃ |
5℃ ~70℃ |
Temp. Stability@37℃ |
±0.2℃ |
±0.2℃ |
Platform Temp. Uniformity |
≤±0.5℃ |
≤±0.5℃ |
Temp. Display Accuracy |
0.1℃ |
0.1℃ |
Heating Speed Range |
≤25min (20℃ to 70℃) |
≤25min (20℃ to 70℃) |
Time Range |
1min ~99h59min or shot mix |
1min ~99h59min or shot mix |
Sample Capacity |
2 Pieces of Plates
(Height<40mm) |
4 Pieces of Plates
(Height<40mm) |
Voltage |
AC 220V / AC 110V, 50/60Hz |
AC 220V / AC 110V, 50/60Hz |
Power |
150W |
250W |
Fuse |
250V, 1A/2A, Ф5x20 |
250V, 3A/5A, Ф5x20 |
Dimension (WxDxH) |
284 x 264 x 157mm |
345 x 310 x 178mm |
Net Weight |
6.7kgs |
10.5kgs |
. |
