히팅/쿨링 진탕 블럭 배양기, Thermo Shaking Dry Bath, MTC-100
* 쿨링+히팅+진탕 : MTC 100(0℃~100℃)
* 히팅+진탕 : DTC 100?(RT+5℃ ~100℃)
* 다양한 종류의 Plate, Block, Rack 진탕가능
* 다양한 종류의 튜브 사용가능 : 0.2 ~ 50ml
* 최고 5단계 온도, 진탕,시간 프로그램사용 가능
* 강력한 쿨링과 히팅능력
블럭이 포함되지 않은 상태의 공급가 입니다.
MTC-100/MTH-100 Thermo Shaker Incubator is thermo shaker incubator with fast mixing speed and integrates four kinds of function mixing,
shaking and heating function and cooling function. (MTH-100 integrates three function mixing, shaking and heating function.)
Combined with intelligent operation design, it not only can mix various micro volume tube, PCR plate, deep hole plate and micro plate and
other common laboratory supplies, but also equipped with the function of vortexing and heating all kinds of tubes. It can meet the needs of different users.
특징
u Perfect radius and excellent dimensional technology blend with
adjustable mixing speed.
u Programmable. Efficient shaking and temperature control.
u Restore from power off, recover to the pre-status automatically.
(deleted)
u Microprocessor controlled incubator. Good linearity of temperature
control. Precise control of the shaking speed.
u Timing function. Time range is from 0 to 100hours.
u Various blocks to exchange, convenient for replacement.
u Built-in temperature calibration function and short mixing function.
u DC brushless motor drive, long life and free of maintenance.
u Multiple safety protection function. Conform to CE safety standards,
safe and reliable.
u Various of blocks for optional choice.
3-in-1 model
u Plate (shaking and mixing)
PCR plates (skirted, semi-skirted, nun skirted)
384 well PCR plate
96- and 384- deep well plates
u MTPs, enzyme labeled plate
Tube holders (shaking and mixing)
0.2ml PCR tubes and PCR strips
0.5ml Micro-test tubes
1.5ml/2.0ml Micro-test tubes
u Blocks (shaking, mixing, incubator)
Refer to “Exchangeable blocks for MTH-100/MTC-100
규격
Model |
MTC-100
(cooling) |
MTH-100
(heating) |
Temp. |
0℃~100℃ |
RT+5℃
~100℃ |
Block temp. uniformity |
≤±0.3℃ |
Temp. accuracy |
±0.3℃ |
Display accuracy |
0.1℃ |
Heating platform temp. accuracy |
< 0.5℃ (detect at 37℃) |
Shaking speed
(rpm) |
300~1500 |
300~2000 |
Shaking orbit |
3mm (horizontal) |
Timing range |
99hr59min |
Heating time |
<20min (20℃ to 100℃) |
Cooling time |
≤25min from R.T. to R.T.-20℃ (detect below 30℃) |
/ |
Cooling speed |
≥7℃/min (From 100℃ to 20℃), ≥1.2℃/min ( from R.T. to
R.T.-20℃) |
/ |
Max. power |
200W |
Dimension |
L270 x W196 x H170mm |
Net weight |
8.3kg |
6.8kg |
Block selection |
Refer to “Exchangeable blocks
for MTC-100/MTH-100 series” |
액세서리
Type |
Parameter |
Max. Temp |
A |
96x0.2ml PCR plate |
100℃ |
B |
54x0.5ml |
100℃ |
C |
35x1.5ml |
100℃ |
D |
35x2.0ml |
100℃ |
E |
20x0.5ml + 15x1.5ml |
100℃ |
F |
24xdia. ≤Φ12mm |
100℃ |
G |
32x0.2ml + 25x1.5ml |
100℃ |
H |
32x0.2ml + 10x0.5ml + 15x1.5ml |
100℃ |
I |
103x67x30 (Water bath block) |
100℃ |
J |
96x0.2ml plate (Flat bottom) |
100℃ |
K |
24x5ml (max. speed to 600rpm) |
100℃ |
L |
12x15ml (max. speed to 600rpm) |
100℃ |
M |
6x50ml (max. speed to 600rpm) |
100℃ |
N |
Customized |
100℃ |
Cover A |
Suit for block A~J |
/ |
Cover B |
Suit for block K, L, M |
/ |
MIX-A |
96x0.2ml tube stand |
/ |
MIX-B |
24x0.5ml tube stand |
/ |
MIX-C |
24x1.5/2.0ml tube stand |
/ |
.
|
