Mini Centrifuge, Mini-4K, 소형 원심분리기
The mini centrifuge series MINI-4K/6K/7K/10K/10K+ is perfect designed with novel and unique appearance.
It is pretty and skillful, equipped with 2 types of rotors and several tube carriers for 2.0mL / 1.5mL / 0.5mL / 0.2mL tubes
and 0.2mL x 8 PCR tube strips. It is designed user-friendly.
Open / Close the cover will automatically start / stop the centrifuge.
Mini centrifuge series are built-in timing function.
Application
u Extract serum from blood
u Extract the supernatant from a variety of samples
u Rapid subsidence of samples
u Separation of trace blood cells
u Microbial sample processing
u PCR experimental division centrifugal
특징
u Large radius rotor with 8tube holes, centrifugal force is 1.5 times bigger than ordinary 6hole rotor at the same rolling speed.
u The cover press-button is outward designed with start / stop function. Press the button, the cover will open automatically to 95º
which is very convenient for one-hand operation.
u The rotor is clip-on fixed. Very convenient for rotors exchanging yet fixed solid reliable.
u LED display speed (MINI-10K+) and timing.
u Working silent and stable. Free-maintenance motor, long-life and safe.
u Delicate appearance yet multi-purpose to meet different experiments.
규격
Model |
Mini-4K |
Mini-6K |
Mini-7K |
Mini-10K |
Mini-10K+ |
Speed |
4,000 rpm |
6,000 rpm |
7,000 rpm |
10,000 rpm |
3,000 ~ 10,000 rpm |
(1,000 rpm step) |
RCF |
1,200 g |
3,000 g |
3,400 g |
7,500 g |
1,000 ~ 7,500 g |
Sample
capacity |
8x2.0mL/1.5mL/0.5mL/0.2mL tube
(additional 0.5mL & 0.2mL tube carriers)
2x8x0.2mL PCR tube strip |
8x2.0mL/1.5mL/0.5mL/0.2mL tube
(additional 0.5mL & 0.2mL tube carriers) |
8x2.0mL/1.5mL/0.5mL/0.2mL tube
(additional 0.5mL & 0.2mL tube carriers)
2x8x0.2mL PCR tube strip
(tube strip only used when speed≤6000rpm) |
Time range |
1 s ~ 99 min 59 s |
1 s ~ 999 min |
Noise |
≤45 dB |
≤55 dB |
Dimension |
176 x 156 x 121 mm |
Weight |
≤1.5kg |
Power |
220V / 110V, 50 ~ 60Hz |
. |
