듀얼 히팅/쿨링 블록, Dual Dry Bath Incubator, BTH-100
BTC-100D / BTH-100D / BTH-100 Dual temperature control dry bath incubator has high precision of
temperature control and good sample preparation parallelism with microprocessor-controlled thermostat to replace the
traditional water bath devices. It can be widely used in the cultivation and preservation of samples ,DNA amplification, the
electrophoresis of denaturation and serum coagulation. Application sectors throughout pharmaceutical, chemical, food safety,
environment, quality inspection, etc. BTC series are pride of its compact appearance and excellent performance.
특징
u OLED display, simple interface, double time and temperature setting, means simultaneous temperature and diminishing time display.
uUnique dual temperature control slot can individually control temperature to make sure non interference. One equipment to meet
the demand for more experiments. (하나의 기기로 듀얼 컨트롤이 가능)
u Fast heating speed, uniform heating, accurate temperature control, high stability, low energy consumption and no noise.
u Built in temperature calibration function, automatic fault detection and buzzer alarm function.
u Built in over-temperature protection device, safe and reliable, enhance the service life of the machine.
u Product designed compact and tight, occupied little space. Using freer and easier.
u Various blocks for convenient replacement, easy for cleaning and disinfection. (0.2~50mL 튜브까지 다양한 종류의 블록
u 사용이 가능하며, 튜브 사이즈에 따라 블록의 사용 수량이 달라짐)
u Perfect high module sealing cartridge with cover can make 15 / 50ml high module totally enclosed with dry bath
u Heated model can option external sensors to control temperature more accurately and directly.
u 15mL & 50mL 튜브용 블록(BT-F,BT-G) 사용 시, 높은 커버 사용 (높은 커버 옵션)
u 낮은 커버 2개 기본 포함, 블록 옵션
규격
Model |
BTH-100D
(Dual Heating) |
BTH-100
(Cooling
& Heating) |
BTC-100D
(Dual Cooling) |
Temp. control range |
R.T.+5℃ ~ 100℃ (Heating) |
- |
- |
-10℃ ~ 100℃ (Cooling) |
Temp. stability |
≤±0.5℃ (@100℃) |
Max temp. difference |
0.3℃ (@40℃) |
Block temp. uniformity |
≤±0.3℃ |
Display accuracy |
0.1℃ |
Heating time |
≤15min (20℃~100℃) |
Time range |
1min ~ 99hr59min |
Max. temperature |
100℃ |
Cooling time |
- |
≤25min (R.T. down to 25℃),
(Nature down to 26℃) |
Input voltage |
AC220/110V, 50/60Hz |
Power |
150W |
170W |
200W |
Fuse protector |
250V, 2A/4A, ø5x20 |
Dimension |
W240 x D260 x H168 mm |
Net weight |
2.6kg |
액세서리
Type |
Tube diameter |
Max. capa. |
BT-A |
24 x 0.2mL centrifuge tube |
8 pieces |
BT-B |
12 x 0.5mL centrifuge tube |
8 pieces |
BT-C |
6 x 1.5mL centrifuge tube |
8 pieces |
BT-D |
6 x 2.0mL centrifuge tube |
8 pieces |
BT-E |
96 x 0.2mL pcr plate |
2 pieces |
BT-F |
6 x 15mL centrifuge tube |
4 pieces |
BT-G |
3 x 50mL centrifuge tube |
4 pieces |
BT-H |
Customized |
Customized |
BT-HC |
F/G Block용 높은 케이스 |
2 pieces |
BT-HH |
Case-Hi용 커버(BT-F, G용) |
2 pieces |
. |
