 BIO관련기기  히팅/쿨링블록

상품명 : 히팅블록/DKT200-4
· 정가금액 :   0원
· 판매금액 :   1,144,000원 (수량,부품변경,추가제품 반영금액)
· 제조원 :   MiuLab
· 제품담당자 :   (주)랩테크
· 모델명 :   DKT200-4
· 수량 :


.



히팅블록, Thermo Dry Bath, DKT200-4




4개의 블록이 포함된 상태의 금액입니다.





DKT200 Dry bath incubator is a microprocessor-controlled device, high precision of temperature control, sample preparation parallelism,
as an alternative to the traditional water bath device. It can be widely used in various samples of the cultivation, preservation and reaction.
Application of industry includes the pharmaceutical, chemical, food safety, environment, quality inspection.



특징
u LED display, simple interface. Cool and compact designed appearance.
u Fast heating speed, uniform heating, accurate temperature control, high stability, low energy consumption and no noise.
u Built in temperature calibration function, automatic fault detection and buzzer alarm function.
u Built in over-temperature protection device, safe and reliable use, prolong the service life of the machine.
u Product designed compact and tight, occupied little space, free and easy.
u Various blocks for convenient replacement, easy for cleaning and disinfection.
u “DKT200-2A” Model can achieve two independent heating modules, thermostats, unique combo designed to meet the needs of
    more experimental.




규격
Model DKT200-1 DKT-200-2 DKT200-2A DKT200-4
Temp. control range RT+5℃ ~ 150℃ RT+5℃ ~ 120℃
Heating time ≤ 30min
(20℃ -> 150℃)
≤ 30min
(20℃ -> 120℃)
Temp. control accuracy ≤ ±1℃ (at 100 ~ 150℃)  /  ≤ ±0.5℃ (at 40 ~ 100℃)
Block temp. discrepancy 0.3℃ (at 40℃)
Block temp. uniformity ≤ ±0.5℃
Display accuracy 0.1℃
Blocks quantity 1 block 2 blocks 2 blocks
(개별컨트롤)
4 blocks
Timing range 99h 59min
Max. temp. 150℃ 120℃
Max. power 200W 400W 600W
Dimension (mm) 230 x 220 x 95 260 x 220 x 95 260 x 290 x 95 360 x 220 x 95
Block selection Refer to “Exchangeable blocks for DKT series”



   Exchangeable blocks
DT01 6 mm x 42 95.5x76.5x50 mm
DT02 7 mm x 42
DT03 10 mm x 20
DT04 12 mm x 20
DT05 13 mm x 20
DT06 15 mm x 12
DT07 16 mm x 12
DT08 19 mm x 12
DT09 20 mm x 6
DT10 26 mm x 6
DT11 28 mm x 4
DT12 40 mm x 2
DT13 0.5 mL x 42
DT14 1.5 mL x 24
DT15 2.0 mL x 24
DT16 0.2 mL x 48
DT17 0.2 mL x 96 78x114x26 mm
DT18 Flat(no hole)
96 micro-plate
81x123x19 mm
DT19 Customized Customized
